HK Audio LUNAR 112 XA - Active 2-way 12" Speaker

Overview:

The HK Audio LUNAR 112 XA 12" Active 2-way Speaker delivers powerful, detailed sound for live performances, DJs, and speech reinforcement. Its 12-inch driver, 1,200W peak Class-D amplification, and 32-bit DSP provide controlled audio performance. Bluetooth 5.4 with TWS adds wireless flexibility, while the speaker can operate independently, as a stage monitor, or with a subwoofer.

Key Features:

•    32-bit DSP with FIR Filtering: Provides phase correction and detailed audio with consistent                dynamics across the frequency range.
•    Four Sound Presets: Music, Monitor, Voice, and External Sub modes simplify setup for different        applications.
•    1,200W Class-D Amplification: Delivers 1,200W peak power with efficient bi-amped                                performance and silent fanless operation.
•    Bluetooth 5.4 with TWS: Supports wireless playback and True Wireless Stereo pairing for                    flexible system setups.
•    Flexible Application Options: Use it full-range, as a stage monitor, or with a subwoofer for                    greater versatility.
•    Robust German-Built Cabinet: The MDF cabinet features an acrylic enamel finish and multiple          rigging options.
•    Portable 20.5kg Design: Two SingleGrip handles make carrying and setup easier for mobile                  applications.

Specifications:

System & DSP

•    Concept: Active 2-way loudspeaker (bass reflex)
•    DSP: 32-bit digital signal processor with FIR filter and phase correction
•    Sample Rate: 48 kHz
•    Latency: Approx. 3 ms
•    Speaker Protection: Subsonic filter, multiband limiter, peak & RMS limiter

Drivers

•    Low/Mid: 1 × 12” cone speaker with 2.5” voice coil
•    High: 1 × 1” compression driver with 1.4” voice coil
•    Horn: Constant directivity horn for smooth dispersion

Performance

•    Maximum SPL (peak): 130 dB
•    Sensitivity (1 W/1 m): 110 dB
•    Frequency Range (-6 dB): 62 Hz – 21 kHz
•    Frequency Range (-10 dB): 56 Hz – 22 kHz
•    Dispersion Angle (-6 dB): 90° horizontal × 55° vertical

Amplification & Power

•    Power Amplifier: Class-D, bi-amped
•    RMS Power Output: 600 W
•    Peak Power Output: 1200 W
•    Power Consumption: ~0.5 A @ 220–240 V AC (1/8 output)
•    Power Consumption: ~0.9 A @ 100–120 V AC (1/8 output)

Inputs & Outputs

•    Analog Input: 1 × XLR/TRS combo (Mic/Line), switchable sensitivity
•    Thru Output: 1 × XLR (pass-through of analog input)
•    Mix Out: 1 × XLR (summed analog + Bluetooth signal)
•    Bluetooth: Yes — Bluetooth 5.4 with True Wireless Stereo (TWS)

Presets & Controls

•    Filter Presets: Music, Monitor, Voice, External Sub
•    Crossover Frequency: 1.9 kHz FIR X-Over with 60 dB/octave

Mechanical & Rigging

•    Cabinet Material: MDF (medium-density fiberboard)
•    Cabinet Surface: Acrylic enamel finish
•    Color: Jet Black (RAL 9005)
•    Front Grille: 1.5 mm steel grille backed with acoustic foam
•    Rigging Points: 4 × M8
•    DuoTilt Flanges: 3° / 7° tilt options
•    Monitor Angle: 33° integrated
•    Optional: U-bracket mounting points for ceiling installations

Mobility

•    Carrying Handles: 2 × SingleGrip
•    Dimensions (W × H × D): 39 × 65.4 × 35.5 cm
•    Dimensions (Imperial): 15-23/64 × 25-47/64 × 13-15/16 inches
•    Weight: 20.5 kg (45.20 lbs)

Streaming Compatibility:

Bluetooth 5.4
True Wireless Stereo (TWS)

Flexible PA Performance:

The HK Audio LUNAR 112 XA is suited to DJs, live musicians, speech reinforcement, mobile setups, rental environments, and fixed installations. Its flexible configuration also supports use with the PORTABLE SUB series.
