PowerWorks X2004BT-USB - Channel Mixer (8 Mono & 2 Stereo)
Overview:
The PowerWorks X2004BT-USB is a mixer with eight mono channels and two stereo channels. It combines flexible connectivity with detailed EQ control, 99 built-in DSP effects, and +48V phantom power. USB and Bluetooth support digital playback, while the recording function adds further flexibility. Multiple outputs, visual level displays, and smooth 60mm faders provide practical control for varied audio setups.
Key Features:
• 8 Mono and 2 Stereo Channels: Connect multiple audio sources using eight mono channels and two stereo channels for flexible mixing.
• Balanced Low-Noise Microphone Inputs: Balanced microphone inputs provide cleaner signal handling for vocals, instruments, and other audio sources.
• +48V Phantom Power: Each microphone channel provides +48V phantom power for compatible condenser microphones.
• 26dB Channel Attenuation: The 26dB attenuation switch helps control higher input levels and reduce potential signal distortion.
• Flexible EQ Control: 4-band EQ shapes mono channels, while 3-band EQ provides tonal control for stereo channels.
• 99 Built-In DSP Effects: Choose from 99 DSP effects to add processing, depth, and creative options to your mix.
• USB and Bluetooth Playback: Play MP3 files through USB drives or use Bluetooth for convenient wireless audio playback.
• Flexible Audio Routing: Two AUX sets and one FX output provide options for monitor mixes and external effects.
• Precision Fader Control: 60mm stroke high-analysis faders provide smooth adjustments and controlled transitions between audio sources.
• Detailed Level Monitoring: The three-color electric screen and dual 12-segment display provide clear signal-level feedback.
• 7-Segment Graphic Equalizer: Fine-tune the overall output using the dedicated 7-segment stereo graphic equalizer.
• LR Monitor Output: The LR channel monitor output supports accurate monitoring during recordings and live performances.
Specifications:
• Channels: 8 Mono Channels, 2 Stereo Channels
• Microphone Inputs: Balanced, Low-Noise
• Phantom Power: +48V (Per Microphone Channel)
• Attenuation Switch: 26dB (Per Mono Channel)
• EQ: Mono Channels: 4-Band EQ, Stereo Channels: 3-Band EQ
• Mute Switch: Yes (Each Channel)
• Auxiliary Outputs: AUX: 2 Sets, FX: 1 Set
• AUX Send Control: 2 Groups, Pre-Self-Locking Press
• Faders: Stroke High Analysis
• DSP Effects: 99 Built-In Effects
• MP3 Playback: Built-In Digital Display MP3 (U-DISK MP3 Input), Bluetooth Playback
• Recording: One-Key Recording Function
• Graphic Equalizer: 7-Segment Stereo Graphic Equalizer
• Level Display: High-Precision Three-Color Electric Screen, Dual 12-Segment Flow Level Display Output
• Monitor Output: LR Channel MONITOR Output
• Power Supply: Built-In Switching Power Supply, Suitable for 110V-220V AC Power Supply
Streaming Compatibility:
No specific streaming services were provided.
Bluetooth playback is supported.
Flexible Mixing for Multiple Audio Sources:
The PowerWorks X2004BT-USB suits musicians, sound engineers, and audio professionals needing broad mixing control. Its channel layout, DSP effects, EQ options, routing, and monitoring features support varied audio applications. USB, Bluetooth, and one-key recording also provide convenient options for managing and capturing audio.
